ShopKVM SwitchesStarTech.com 16 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 19" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support
StarTech.com 16 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 19" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support
View 1
View 2
View 3
View 4
View 5

StarTech.com 16 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 19" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support

£1374.70

£1649.64 inc. VAT

Low Stock(4)MPN: RKCONS1916K
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com 16 Port Rackmount KVM Console with 6ft Cables, Integrated KVM Switch with 19" LCD Monitor, Fully Featured 1U LCD KVM Drawer- OSD KVM, Durable 50,000 MTBF, USB + VGA Support
19in. LCD KVM Console (RKCONS1916K)
KVM console with KVM switch
16 ports
PS/2, USB
US
19"
rack-mountable

Product Overview

AI-generated summary

At ~£1.4k ex-VAT, this StarTech 1U rack KVM drawer is the sort of purchase you make when you *need* something rack-friendly and hands-off for daily admin work—not when you’re just trying to “get a KVM in the building.” The integrated LCD plus OSD controls are genuinely practical for servers in a tight data centre, especially if you occasionally have to troubleshoot before you’ve got proper out-of-band access. The USB + VGA angle also means it won’t feel too restrictive if you’ve got mixed device types, which is common in older estates.

That said, I wouldn’t buy it casually. If your environment is modern and you already rely on iDRAC/iLO/IPMI or a dedicated management fabric, a KVM drawer can be overkill, and the cost is hard to justify versus simpler, cheaper switching approaches. Also, with KVM drawers, the real risk is long-term usability—these units live a rough life in racks and downtime is expensive. If you can’t be confident you’ll use the local console regularly, you’ll end up paying for convenience you don’t really leverage.

Who it suits: UK SMBs and mid-market teams who run server rooms/closets without always-on out-of-band management, or who have a small number of racks that benefit from a local console at the same height as the gear. Who should skip: orgs with strong OOB management and no operational need for a built-in screen, or buyers chasing value where a basic remote approach would do the job cheaper.

Specifications

Display

Display diagonal19 "
Display resolution1280 x 1024 pixels
DisplayTFT LCD
Display brightness250 cd/m²
Contrast ratio (typical)1000:1

Technical details

Mean time between failures (MTBF)50000 h
Product colourBlack
Operating relative humidity (H-H)10 - 80 %
Audio supportN
Daisy chainN

Ports & interfaces

VGA (D-Sub) ports quantity18
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
USB 2.0 Type-A ports quantity2

Keyboard

Built-in touchpadY

Certificates

CertificationPSE, FCC, UL, CE, REACH

Power

Power consumption (typical)23 W
AC adapter input voltage100 - 240 V
Input current1.5 A

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width483 mm
Height43 mm
Depth643 mm
Weight13500 g
Mounting depth (min)605 mm
