ShopHubs & SwitchesTP-Link Omada ES220GMP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
TP-Link Omada ES220GMP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
View 1
View 2
View 3
View 4
View 5

TP-Link Omada ES220GMP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

£190.14

£228.17 inc. VAT

Out of Stock(0)MPN: ES220GMP
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

TP-Link Omada ES220GMP V1.6
Switch
Managed
16 x 10/100/1000 (PoE+) + 2 x 10/100/1000 + 2 x Gigabit SFP
rack-mountable
PoE+ (250 W)

Product Overview

AI-generated summary

The TP-Link Omada ES220GMP is a solid “proper network” switch at a sensible price, especially if you’re already living in the Omada ecosystem (controller + dashboard). For day-to-day office use it’s the kind of unit that just gets on with it: managed VLANs, sensible Layer 2 control, and the PoE side handled in a way that’s typically reliable with the usual Omada AP and camera setups. At **£189.76 ex-VAT**, it’s good value if you need PoE for a couple of endpoints and don’t want to jump straight to bigger, more expensive brands/models.

Who should buy it: small offices, meeting rooms, retail units—anywhere you want centralized management (rather than “set it and forget it” unmanaged gear) and you’ll be powering a handful of PoE devices. Who should *not* buy it: if you’re expecting heavy growth, lots of high-throughput aggregation, or lots of advanced requirements beyond straightforward L2 switching, you’ll probably outgrow the class of switch quickly and start feeling boxed in. In short: buy it if you want dependable managed PoE on a budget; skip it if you’re building something that needs to scale aggressively or demands more than typical SMB networking.

Specifications

Management features

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportY
Web-based managementY
Cloud-managedY

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity18
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity18
SFP module slots quantity2
Power connectorAC-in jack

Network

Networking standardsIEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G supportN
Zero Touch Provisioning (ZTP)Y
Port mirroringY
Flow control supportY

Data transmission

Switching capacity40 Gbit/s
Forwarding rate29.76 Mpps
MAC address table8000 entries
Store-and-forwardY
Jumbo frames supportY

Security

DHCP featuresDHCP client
IGMP snoopingY
Loop protectionY
Queue scheduling algorithmsWeighted Round Robin (WRR)

Design

Rack mountingY
StackableN
Product colourBlack
LED indicatorsY
Number of fans2 fan(s)

Performance

Flash memory64 MB
Noise level41.5 dB
Firmware upgradeableY
Mean time between failures (MTBF)310550.7 h

Power

Power sourceAC
Power supply includedY
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Power consumption (max)289.7 W
