ShopKVM SwitchesStarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD
StarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD
View 1
View 2
View 3
View 4

StarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD

£483.10

£579.72 inc. VAT

Low Stock(3)MPN: SV1631DUSBU
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD (SV1631DUSBU)
KVM switch
16 x KVM port(s)
1 local user
desktop
for P/N: RK3236BKF, RK4236BKB, RKCONS1701, RKCONS17HD, RKCONS1901, RKCONS1908K, RKCONS1916K

Product Overview

AI-generated summary

At ~£483 ex-VAT, this StarTech 16-port USB rack KVM with OSD is only “good value” if you truly need 16 discrete server connections in a 1U footprint and you’ll use the OSD-driven switching day to day. In real deployments, the pain point isn’t usually the first install—it’s living with latency, keyboard/mouse weirdness, and constant edge-case behavior. StarTech tends to be fairly solid on compatibility (especially with USB devices) and the OSD matters because it speeds up recovery when you need to identify/route consoles quickly without crawling behind the rack.

That said, I wouldn’t buy this for a small setup or for anything where you only need a handful of servers. 16-port units like this often end up being “bought for the future” and then the ports sit unused; meanwhile you’re still paying for the complexity and power/space of a bigger switch than you need. It’s a sensible choice for UK IT teams managing multiple legacy or “no local access” systems in a rack—datacentre-ish, server rooms, managed environments—but if your world is mostly modern hardware with remote management, you may be better served by lighter-touch remote console solutions instead of tying up console switching to a hardware KVM.

Specifications

Ports & interfaces

Number of computers controlled16
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
Console portsUSB A,VGA (D-Sub)

Performance

Maximum resolution1920 x 1440 pixels
Plug and PlayY
Daisy chainY

Design

Rack mountingY
Rack capacity1U
Product colourBlack
Housing materialSteel
LED indicatorsY

Display

Built-in displayN

Power

Input voltage110-240 V
Input current0.8 A
Output voltage12 V
Output current1.5 A
Power plug typeType M

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)5 - 80 %

Weight & dimensions

Width540 mm
Depth180 mm
Height45 mm
Weight3100 g

Packaging data

Package width89 mm
Package depth468 mm
Package height264 mm
Package weight3530 g
