ShopKVM SwitchesStarTech.com Dual Rail Rackmount KVM Console HD 1080p - Single Port DVI/VGA KVM w/17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables - USB Support - 44230 MTBF
StarTech.com Dual Rail Rackmount KVM Console HD 1080p - Single Port DVI/VGA KVM w/17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables - USB Support - 44230 MTBF
View 1
View 2
View 3
View 4
View 5

StarTech.com Dual Rail Rackmount KVM Console HD 1080p - Single Port DVI/VGA KVM w/17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables - USB Support - 44230 MTBF

£942.71

£1131.25 inc. VAT

Out of Stock(0)MPN: RKCOND17HD
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com Dual Rail Rackmount KVM Console HD 1080p, Single Port DVI/VGA KVM with 17" LCD Monitor for Server Rack, Fully Featured 1U LCD KVM Drawer with Cables, USB Support, 44230 MTBF
Single Port Console (RKCOND17HD)
KVM console with KVM switch
1 ports
USB
17.3"
rack-mountable
1920 x 1080 Full HD (1080p) @ 60 Hz

Product Overview

AI-generated summary

If you’re looking for a “real” 1U rack console that doesn’t turn into a cabling nightmare every time you need access, StarTech’s dual-rail LCD KVM drawer is the kind of tool you buy and then actually forget about. In day-to-day server-room work it’s genuinely convenient: one drawer in the rack, integrated screen, and a straightforward console workflow for installs, BIOS/firmware work, and occasional recovery when iDRAC/iLO is down or locked. The value comes from reducing time—less swapping monitors/keyboards, less mucking about with adapters, and fewer points of failure around KVM signaling.

That said, £942.67 ex-VAT is steep enough that I’d only recommend it if you *need* the form factor: a proper drawer-style console for a rack, and you’re buying for a multi-server environment where you’ll use it more than “once in a blue moon.” If your use case is light (or you already have reliable out-of-band management), you’ll probably get better ROI by using IP KVM/remote management or a simpler local console approach. Also, make sure the connectivity matches your targets—this is a single-port DVI/VGA-style setup, so it’s not for environments where you regularly need to jump between multiple machines without additional switching hardware. Overall: solid, practical, and built for server-room reality—but only worth it when local KVM convenience is a business requirement, not just a preference.

Specifications

Display

Display diagonal17.3 "
Display resolution1920 x 1080 pixels
DisplayTFT LCD
Display brightness250 cd/m²
Contrast ratio (typical)650:1

Technical details

MaterialSteel
Mean time between failures (MTBF)44230 h
Product colourBlack
Operating relative humidity (H-H)0 - 80 %
Rack mountingY

Ports & interfaces

3.5 mm (1/8-inch) outY
3.5 mm (1/8-inch) inY
DVI connector typeDVI-D
DVI input ports1
DVI output ports1

Keyboard

Hot keysY

Certificates

CertificationCE, FCC, UL, REACH

Power

Power consumption (typical)19.4 W
AC adapter input voltage100 - 240 V
Input current1 A

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width480 mm
Height44 mm
Depth727 mm
Weight13600 g
Mounting depth (min)650 mm
