ShopHubs & SwitchesTP-Link Omada SG5428X network switch Managed L3 Gigabit Ethernet (10/100/1000) Black
TP-Link Omada SG5428X network switch Managed L3 Gigabit Ethernet (10/100/1000) Black
View 1
View 2
View 3
View 4
View 5

TP-Link Omada SG5428X network switch Managed L3 Gigabit Ethernet (10/100/1000) Black

£375.89

£451.07 inc. VAT

Out of Stock(0)MPN: SG5428X
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

TP-Link Omada SG5428X V1
Switch
L3 Lite
Managed
24 x 10/100/1000 + 4 x 10Gb Ethernet SFP+
rack-mountable

Product Overview

AI-generated summary

For ~£376 ex-VAT, the TP-Link Omada SG5428X is one of those “sensible, grown-up” switches that’s great if you’re standardising on Omada for the rest of your network. The big win isn’t just that it’s managed—it’s that it tends to play nicely with Omada’s controller and the whole environment feels more coherent than mixing-and-matching vendors. If you’ve got VLANs, multiple subnets, and you don’t want to babysit the gear, this is the kind of switch that quietly saves you time (and future headaches) in day-to-day operations.

Who should buy it: small-to-mid UK businesses, school/college suites, and IT teams who want L3 features and solid rack hardware without spending “enterprise” money. It’s especially worth considering when you expect to grow beyond a basic flat network. Who might not: if you only need simple managed switching, the price is probably more than you need—there are cheaper Omada options that’ll do the job. Also, if your team doesn’t already know Omada well, spend a bit of time validating the exact features you rely on (routing behaviour, management style) in a test setup—support and documentation are usually fine, but alignment with your existing stack matters.

Specifications

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportY
Web-based managementY
Cloud-managedY

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity24
SFP+ module slots quantity4
USB Type-C ports quantity1

Network

Networking standardsIEEE 802.3af,IEEE 802.3at,IEEE 802.3bt
10G supportY
Port mirroringY
Link aggregationY
Broadcast storm controlY

Data transmission

Switching capacity128 Gbit/s
Forwarding rate95.23 Mpps
MAC address table16000 entries
Store-and-forwardY
Jumbo frames supportY

Security

DHCP featuresDHCP relay,DHCP server
Access Control List (ACL)Y
IGMP snoopingY
Security algorithmsSNMP,SNMPv2,SNMPv3
MAC address filteringY

Multicast features

Multicast supportY

Design

Rack mountingY
StackableY
Product colourBlack
LED indicatorsY

Performance

Physical stacking (units)4
Built-in processorY
Processor manufacturerARM
Processor frequency1200 MHz
Memory typeDRAM
