ShopKVM SwitchesStarTech.com Rackmount KVM Console - Single Port VGA KVM with 17" LCD Monitor for Server Rack - Fully Featured Universal 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF
StarTech.com Rackmount KVM Console - Single Port VGA KVM with 17" LCD Monitor for Server Rack - Fully Featured Universal 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF
View 1
View 2
View 3
View 4
View 5
View 6

StarTech.com Rackmount KVM Console - Single Port VGA KVM with 17" LCD Monitor for Server Rack - Fully Featured Universal 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF

£682.46

£818.95 inc. VAT

Low Stock(14)MPN: RKCONS1701
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com Rackmount KVM Console, Single Port VGA KVM with 17" LCD Monitor for Server Rack, Fully Featured Universal 1U LCD KVM Drawer with Cables & Hardware, USB Support, 50,000 MTBF
LCD KVM Concole Drawer (RKCONS1701)
KVM console with KVM switch
1 ports
USB
17"
rack-mountable
1280 x 1024 @ 60 Hz

Product Overview

AI-generated summary

At £682.44 ex-VAT, this StarTech 1U rackmount KVM drawer is a “buy it if you actually need it” kind of product—not a casual upgrade. The big win is operational: having a 17" integrated LCD drawer with the cabling/hardware bundled makes rack work faster and cleaner, and that matters when you’re deploying or servicing multiple servers in tight spaces. It’s especially suitable for UK data rooms where you want a local console for BIOS/recovery and you don’t want to rely solely on remote tools for every incident. If your environment is predominantly VGA-friendly and you’re standardising on a universal local console method across a few server generations, this will feel sensible and predictable.

I’d hesitate if you’re expecting modern, high-definition console experiences or broad compatibility beyond older display outputs—this is the “server recovery and everyday administration” lane, not the “premium workstation” lane. Also, if you already have solid out-of-band management (dedicated iDRAC/iLO/IPMI with good workflows), the value proposition drops: you’re paying for convenience you may not use often. Overall: good choice for IT teams managing racks who want reliable local access and don’t want to piece the solution together—just make sure your servers and intended connections align, otherwise you’ll end up spending money on adapters and workarounds instead of saving time.

Specifications

Display

Display diagonal17 "
Display resolution1280 x 1024 pixels
Display brightness250 cd/m²
Contrast ratio (typical)1000:1
Viewing angle, horizontal170 °

Technical details

MaterialSteel
Mean time between failures (MTBF)50000 h
Operating relative humidity (H-H)10 - 80 %
Rack mountingY
Daisy chainN

Ports & interfaces

Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA

Certificates

CertificationCE, FCC, PSE, UL

Power

Power consumption (typical)13 W
AC adapter input voltage100 - 240 V
Input current1.5 A

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width448 mm
Height471 mm
Depth42.5 mm
Weight11600 g
Mounting depth (min)450 mm

Packaging data

Package weight17100 g
Package width615 mm
Package depth765 mm
Package height185 mm
