StarTech.com 8 Port SATA PCIe Card - PCI Express 6Gbps SATA Expansion Adapter Card with 4 Host Controllers - SATA PCIe Controller Card - PCI-e x4 Gen 2 to SATA III - SATA HDD/SSD
View 1
View 2
View 3
View 4
View 5
View 6

StarTech.com 8 Port SATA PCIe Card - PCI Express 6Gbps SATA Expansion Adapter Card with 4 Host Controllers - SATA PCIe Controller Card - PCI-e x4 Gen 2 to SATA III - SATA HDD/SSD

£84.30

£101.16 inc. VAT

Low Stock(9)MPN: 8P6G-PCIE-SATA-CARD
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com 8 Port SATA PCIe Card, PCI Express 6Gbps SATA Expansion Card with 4 Host Controllers, SATA PCIe Controller Card, PCI-e x4 Gen 2 to SATA III Adapter Card, Drive Cables Incl.
Windows/macOS/Linux (8P6G-PCIE-SATA-CARD)
Storage controller
SATA 6Gb/s / SAS 6Gb/s
low profile
PCIe 2.0 x4
black

Product Overview

AI-generated summary

For £82.68 ex-VAT, this StarTech 8‑port SATA PCIe card is the kind of “get things working” part I’d recommend when you need to add a handful of SATA drives to a server or workstation that’s already full. The headline value is that you’re buying a proper expansion controller (not a cheap convertor that turns into a headache under load), and the multi‑host approach generally plays nicer with mixed SSD/HDD setups. If you’re building a small NAS, adding extra drives to a backup box, or expanding a mini‑server with limited SATA headers, it’s a sensible, cost-effective way to increase storage without replacing the whole platform.

Why you *might* avoid it: if you’re expecting it to behave like a full enterprise storage backplane, don’t. A PCIe SATA card like this is still sharing bandwidth through the PCIe link, so it won’t feel snappy if you’re hammering multiple drives at once. Also, check your host’s PCIe slot situation carefully—cards like this can be picky about physical fit, and some systems are fussier about power/BIOS enumeration than others. In short: buy it if you need 8 extra SATA ports with minimal fuss and good compatibility; don’t buy it if your workload is heavy simultaneous I/O across many disks or you’re trying to “turn it into a RAID controller upgrade” on the cheap.

Specifications

Ports & interfaces

Host interfacePCIe
Output interfaceMini-SAS
Expansion card standardPCI 2.0
SATA revision3.0
External mini-SAS ports2

Design

InternalY
Product colourBlack

Features

ChipsetPericom - PI7C9X2G608GP, ASMedia - ASM1061
Data transfer rate (max)6 Gbit/s
S.M.A.R.T. supportY
TRIM supportY

Operational conditions

Operating temperature (T-T)5 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)20 - 80 %

System requirements

Windows operating systems supportedWindows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows Vista x64,Windows XP,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Mac operating systems supportedMac OS X 10.6 Snow Leopard,Mac OS X 10.7 Lion,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks,Mac OS X 11.0 Big Sur,Mac OS X 13.0 Ventura
Linux operating systems supportedY
Server operating systems supportedWindows Server 2003,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019

Technical details

Compliance certificatesRoHS

Weight & dimensions

Width68.6 mm
Depth150 mm
Height14.6 mm
Weight75 g

Packaging data

Cables includedSATA
Mounting brackets includedY
Quick installation guideY
Package width230 mm
Package depth155 mm
