ShopKVM SwitchesStarTech.com 8 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 17" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support
StarTech.com 8 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 17" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support
View 1
View 2
View 3
View 4
View 5
View 6

StarTech.com 8 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 17" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support

£1040.35

£1248.42 inc. VAT

Low Stock(12)MPN: RKCONS1708K
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com 8 Port Rackmount KVM Console with 6ft Cables, Integrated KVM Switch with 17" LCD Monitor, Fully Featured 1U LCD KVM Drawer- OSD KVM, Durable 50,000 MTBF, USB + VGA Support
17in. LCD KVM Drawer (RKCONS1708K)
KVM console with KVM switch
8 ports
USB
17"
rack-mountable
1280 x 1024 @ 60 Hz

Product Overview

AI-generated summary

For £1,040 ex-VAT, this is the kind of KVM you buy when you *need* a proper 1U rack drawer with a built-in screen and you don’t want the faff of separate monitor + keyboard/mouse dongles. The “8-port with integrated 17-inch LCD” approach is genuinely convenient for server rooms, and the OSD makes it workable day to day (not just a “boot it once and forget it” solution). If you’re supporting multiple hosts from a single console point—VM clusters, small-to-mid server rooms, or a managed service desk that wants fast physical access—this will save time and cable chaos. Also, the USB + VGA support is a sensible baseline when you’ve got a mixed bag of server management ports.

That said, I’d be cautious if your use case is light or you already have a decent out-of-band management setup. A KVM LCD drawer is power-hungry, takes up real rack budget, and LCD KVMs are one of those categories where you’ll notice age sooner than with newer console solutions. If you’re mostly doing occasional maintenance, there are often cheaper routes (or even a simpler KVM) that still get the job done without paying for a full “drawer + 17-inch” experience. Bottom line: buy it if you truly benefit from an in-rack, multi-host console with OSD and want something dependable for regular onsite use—skip it if you just need occasional access and can lean on existing remote management.

Specifications

Display

Display diagonal17 "
Display resolution1280 x 1024 pixels
DisplayTFT LCD
Display brightness250 cd/m²
Contrast ratio (typical)1000:1

Technical details

MaterialSteel
Mean time between failures (MTBF)50000 h
Product colourBlack
Operating relative humidity (H-H)10 - 80 %
Rack mountingY

Ports & interfaces

VGA (D-Sub) ports quantity8
Keyboard port typePS/2
Mouse port typePS/2
Video port typeVGA
USB 2.0 Type-A ports quantity2

Keyboard

Hot keysY

Power

Power consumption (typical)13 W
AC adapter input voltage100 - 240 V
Input current1.5 A

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width448 mm
Height619 mm
Depth43 mm
Weight17000 g
Mounting depth (min)560 mm

Packaging data

Package weight19700 g
Package width76 mm
Package depth617 mm
Package height182 mm
