ShopKVM SwitchesStarTech.com 8 Port 1U Rackmount USB KVM Switch Kit with OSD and Cables
StarTech.com 8 Port 1U Rackmount USB KVM Switch Kit with OSD and Cables
View 1
View 2
View 3
View 4

StarTech.com 8 Port 1U Rackmount USB KVM Switch Kit with OSD and Cables

£330.20

£396.24 inc. VAT

Low Stock(3)MPN: SV831DUSBUK
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com 8 Port 1U Rackmount USB KVM Switch Kit with OSD and Cables
Rack mount KVM
VGA KVM Switch
8 Port KVM Switch (SV831DUSBUK)
KVM switch
8 x KVM port(s)
1 local user
rack-mountable

Product Overview

AI-generated summary

StarTech’s 8‑port 1U rackmount KVM kit is the sort of “grown‑up” solution you buy when you need something reliable in a comms room or server cupboard and you don’t want to faff about with desktops, USB hubs, or sketchy adapters. The OSD is a genuine quality-of-life feature (especially with more than a couple of servers), and the fact it’s sold as a kit with cabling makes deployment simpler—less time hunting for the right lead, more time actually getting consoles working. At ~£330 ex‑VAT, it’s not the cheapest way into KVM, but for UK B2B use it’s reasonably priced when you factor in rack form factor, manageability, and fewer “it doesn’t behave in production” moments.

That said, I’d only recommend it if your environment is fairly straightforward: you have a fixed set of machines, you primarily need console switching, and you’re okay with the usual KVM trade-off (you’re centralising access, not troubleshooting complex peripherals). If you’re expecting it to behave like an always-perfect USB device pass-through for everything under the sun (specialist dongles, finicky devices), I’d be cautious—most KVMs are strongest for keyboards/mice/OS console workflows. For 8 systems, this is a solid buy for IT teams that want dependable physical console switching; if you’re only managing a couple of servers, you’d usually be better off spending less on a smaller unit.

Specifications

Ports & interfaces

Number of computers controlled8
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
VGA (D-Sub) ports quantity9

Performance

Maximum resolution1920 x 1440 pixels
Maximum analog resolution1920 x 1440 pixels
Plug and PlayY
Daisy chainY

Design

Rack mountingY
Rack capacity1U
Product colourBlack
Housing materialSteel
CascadableY

Display

On Screen Display (OSD)Y

Power

Input voltage100 - 240 V
Output voltage12 V
Output current1 A
Power consumption (typical)12 W
External power adapterY

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80 %

Weight & dimensions

Width435 mm
Depth180 mm
Height45 mm
Weight2200 g
