ShopNIC & Network AdaptersStarTech.com 4-Port M.2 to SATA Adapter Card, M.2 PCIe 3.0 to SATA HDD/SSD Expansion Card, ASM1064 Chipset, M.2 NVMe to 4x HDD/SSD for Windows/macOS/Linux
StarTech.com 4-Port M.2 to SATA Adapter Card, M.2 PCIe 3.0 to SATA HDD/SSD Expansion Card, ASM1064 Chipset, M.2 NVMe to 4x HDD/SSD for Windows/macOS/Linux
View 1
View 2
View 3
View 4
View 5

StarTech.com 4-Port M.2 to SATA Adapter Card, M.2 PCIe 3.0 to SATA HDD/SSD Expansion Card, ASM1064 Chipset, M.2 NVMe to 4x HDD/SSD for Windows/macOS/Linux

£29.59

£35.51 inc. VAT

Out of Stock(0)MPN: 4P-SATA-M2-ADAPTER
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

StarTech.com 4-Port M.2 to SATA Adapter Card, M.2 PCIe 3.0 to SATA HDD/SSD Expansion Card, ASM1064 Chipset, M.2 NVMe to 4x HDD/SSD for Windows/macOS/Linux
Interface adapter
SATA
M.2 Card
green

Product Overview

AI-generated summary

For £29.63 ex-VAT, this is the kind of “get it working” M.2-to-SATA adapter I’d recommend for small-scale jobs: testing, lab builds, cheap expansion in a desktop/workstation, or turning an M.2 slot into a couple of SATA bays without buying a whole new platform. In real life, the big win is cost and simplicity—put it in, use it, and you’re off. The ASM1064 chipset is broadly proven, and with Windows/macOS/Linux it typically plays nicer than off-brand adapters that behave unpredictably with drives or power management.

That said, I wouldn’t buy this for mission-critical storage, high-write workloads, or anything where you expect it to be “set and forget” in a production server. These adapters can be fussy about power stability and sometimes won’t behave identically across OSs (especially around sleep/hibernate and drive detection timing). Also, it’s a four-bay limit—so if you’re trying to build a serious storage pool, you’ll usually end up fighting bandwidth sharing and queueing behaviour rather than enjoying a clean, SATA-native setup.

**Who should buy:** small offices, IT desks, SMBs expanding a single machine for backups, imaging, media storage, or dev/test rigs on a budget. **Who shouldn’t:** anyone building a reliable NAS/server, expecting maximum throughput, or deploying fleet-wide where consistent behaviour matters more than the low price. If you’re comfortable treating it as an inexpensive adapter (and testing it with your exact SSD/HDD models), it’s good value.

Specifications

Ports & interfaces

Host interfaceM.2
Output interfaceSATA
Expansion card standardPCI 3.0
Internal SATA ports quantity4
Port multiplierY

Design

InternalY
Product colourGreen
LED indicatorsPower
Mean time between failures (MTBF)68555579 h
Hot-swapY

Features

ChipsetASMedia ASM1064
S.M.A.R.T. supportY
TRIM supportY

Operational conditions

Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-20 - 80 °C
Operating relative humidity (H-H)20 - 80 %

System requirements

Windows operating systems supportedWindows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 Enterprise,Windows 11 Enterprise x64,Windows 11 Home,Windows 11 Pro,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64
Mac operating systems supportedMac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Mac OS X 13.0 Ventura,Mac OS X 14.0 Sonoma
Linux operating systems supportedY

Technical details

Compliance certificatesRoHS

Weight & dimensions

Width22 mm
Depth80 mm
Height11 mm
Weight8 g

Packaging data

Cables includedSATA
User guideY
Package width142 mm
Package depth170 mm
Package height30 mm
