ShopCollaboration AccessoriesATEN SN3402 serial server RS-232/422/485
ATEN SN3402 serial server RS-232/422/485
View 1
View 2
View 3
View 4

ATEN SN3402 serial server RS-232/422/485

£197.24

£236.69 inc. VAT

Out of Stock(0)MPN: SN3402
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

ATEN SN3402
Device server
2 ports
100Mb LAN, RS-232, RS-422, RS-485
desktop / wall / DIN rail mountable

Product Overview

AI-generated summary

ATEN’s SN3402 is the kind of serial-to-network box that quietly fixes a lot of “legacy meets modern” headaches. If you’ve got RS-232/422/485 gear sitting on a site that needs to be reachable over Ethernet (access control panels, industrial sensors, ticketing kiosks, old weighing systems, etc.), this is a sensible way to avoid ripping and replacing. For ~£197 ex‑VAT, it’s good value when the alternative is expensive integration work or swapping working hardware—especially in UK B2B environments where serial is still everywhere behind the scenes.

That said, I wouldn’t buy it for anything that doesn’t truly need serial. If you’re expecting “easy plug-and-play” for arbitrary devices, success depends on the device’s serial settings and how your software/client side handles them—so there’s a bit of admin involved (drivers, ports, TCP/UDP behaviour, and sometimes protocol quirks). It’s also not the right tool if you need high-throughput or real-time deterministic performance; it’s for connecting and routing serial, not for replacing a proper industrial comms stack. Overall: buy it if you’ve got specific RS-232/422/485 equipment you must keep, and you can spare a little time to line up configuration—skip it if your requirement is general “network connectivity” rather than true serial integration.

Specifications

Technical details

Serial ports quantity2
Serial interface typeRS-232/422/485
Isolation1.5 kV
Surge protection voltage2 kV
Ethernet LAN data rates10,100 Mbit/s

Ports & interfaces

Ethernet LANY
Ethernet LAN (RJ-45) ports1
Terminal block portY

Power

Power source typeDC
Power consumption (max)1.3 W
Power consumption (typical)1.19 W
Input voltage100 - 240 V
Input frequency50 - 60 Hz

Indication

LED indicatorsPower,Status

Weight & dimensions

Width117 mm
Depth98 mm
Height26 mm
Weight210 g
Package width59 mm

Operational conditions

Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)5 - 95 %

Design

Product colourBlack
Housing materialMetal
Reset buttonY
DIN rail mountingY
SafetyUL 60950-1, UL 62368-1

Packaging content

DIN rail kit includedY
Terminal block includedY
Number of foot pads4 pc(s)
User guideY
