ASUS PRIME H810M-A-CSM Intel H810 LGA 1851 (Socket V1) micro ATX
View 1
View 2
View 3
View 4
View 5
View 6

ASUS PRIME H810M-A-CSM Intel H810 LGA 1851 (Socket V1) micro ATX

£84.49

£101.39 inc. VAT

In Stock(197)MPN: 90MB1KK0-M0EAYC
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

ASUS PRIME H810M-A-CSM
Motherboard
micro ATX
LGA1851 Socket
H810 Chipset
USB-C 3.2 Gen 1, USB 3.2 Gen 2, USB 3.2 Gen 1
Gigabit LAN
onboard graphics (CPU required)

Product Overview

AI-generated summary

The ASUS PRIME H810M-A-CSM is the kind of “just works” micro-ATX board you buy when you want to build a sensible office PC and don’t want drama. For **£89.78 ex-VAT**, it’s priced like a budget platform choice, so you’re not paying for luxury features—you’re paying for a stable chipset board that’s likely to behave nicely with standard components, day-in/day-out use, and the usual UK B2B office workload. If you’re rolling out a batch of identical desktops for admin, finance, light content work, or general staff use, this is the sort of dependable base that won’t slow you down during deployment or troubleshooting.

That said, I wouldn’t buy it if you’re building anything where you’ll be adding lots of expansion later or planning a higher-end path (think more demanding graphics, multiple PCIe add-ins, or lots of “we’ll grow it in future” assumptions). Budget boards like this can be totally fine—but the trade-off is you may hit limits sooner than you’d like. Overall: **good value for a straightforward, low-to-mid spec corporate build**; **less compelling for ambitious upgrade-heavy builds** where you want more headroom from day one.

Specifications

Processor

Processor manufacturerIntel
Processor socketLGA 1851 (Socket V1)
Compatible processor seriesIntel Core Ultra (Series 2)
Supported processor socketsLGA 1851

Memory

Supported memory typesDDR5-SDRAM
Number of memory slots2
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC

Storage controllers

Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,PCI Express 4.0,SATA III
Number of HDDs supported4
Number of storage drives supported6

Graphics

Parallel processing technology supportNot supported
On-board graphics cardN

Internal I/O

USB 2.0 connectors1
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Number of SATA III connectors4
S/PDIF out connectorY
Front panel audio connectorY

Rear panel I/O ports

USB 2.0 ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Ethernet LAN (RJ-45) ports1
PS/2 ports quantity1
HDMI ports quantity1

Network

Ethernet LANY
Ethernet interface typeGigabit Ethernet
LAN controllerIntel I219V
Wake-on-LAN readyY
Wi-FiN

Features

Motherboard chipsetIntel H810
Audio output channels7.1 channels
Product colourBlack
Component forPC
Motherboard form factorMicro ATX
