ShopMotherboardsASUS PRIME B760M-F WIFI Intel B760 LGA 1700 micro ATX
ASUS PRIME B760M-F WIFI Intel B760 LGA 1700 micro ATX
View 1
View 2
View 3
View 4
View 5
View 6

ASUS PRIME B760M-F WIFI Intel B760 LGA 1700 micro ATX

£103.93

£124.72 inc. VAT

Out of Stock(0)MPN: 90MB1N00-M0EAY0
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

ASUS PRIME B760M-F WIFI
Motherboard
micro ATX
LGA1700 Socket
B760 Chipset
USB 3.2 Gen 1
Gigabit LAN, Wi-Fi 6, Bluetooth
onboard graphics (CPU required)

Product Overview

AI-generated summary

For ~£105 ex-VAT, the ASUS PRIME B760M-F WiFi is a sensible “get the job done” motherboard for UK SMB and office builds. The PRIME line tends to be stable and straightforward, and the B760 platform is a good sweet spot if you’re pairing it with a fairly typical Intel CPU and don’t want to play BIOS roulette. It’s especially appealing if you’re building a fleet of PCs or small systems where you care more about reliability, sensible defaults, and hassle-free bring-up than chasing premium features.

That said, I wouldn’t buy this if your workloads are likely to be very high-intensity, or if you need lots of expansion/upgrade headroom right away—this is firmly in the practical, mainstream lane. Also, “good value” hinges on the bundle and your exact CPU/requirements: if you’re planning to spec beyond a standard office/server-like desktop workload, you’ll often get better long-term value by paying a bit more for a board that’s more future-proof for storage and expansion. If your goal is a dependable micro-ATX Intel workstation/office box with built-in wireless, this is a solid, boring choice—in the best way.

Specifications

Processor

Processor manufacturerIntel
Processor socketLGA 1700
Compatible processor seriesIntel Celeron,Intel Pentium Gold,Intel Core i3,Intel Core i5,Intel Core i7,Intel Core i9
Maximum number of SMP processors1
Supported processor socketsLGA 1700

Memory

Supported memory typesDDR5-SDRAM
Number of memory slots2
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC

Storage controllers

Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,SATA III
Number of HDDs supported4
Number of storage drives supported6
RAID supportY

Graphics

Parallel processing technology supportNot supported

Internal I/O

USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of SATA III connectors4
S/PDIF out connectorY
Front panel audio connectorY

Rear panel I/O ports

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports1
PS/2 ports quantity1
VGA (D-Sub) ports quantity1

Network

Ethernet LANY
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiY
Top Wi-Fi standardWi-Fi 6 (802.11ax)
BluetoothY

Features

Motherboard chipsetIntel B760
Audio output channels7.1 channels
Component forPC
Motherboard form factorMicro ATX
Motherboard chipset familyIntel
