ShopRacking & CabinetsAPC Easy Rack PDU, Metered Outlet, 0U, 3 Phase, 22kW, 230V, 32A, (18) C13 and (6) C19 outlets, IEC60309 3P+N+PE inlet
APC Easy Rack PDU, Metered Outlet, 0U, 3 Phase, 22kW, 230V, 32A, (18) C13 and (6) C19 outlets, IEC60309 3P+N+PE inlet

APC Easy Rack PDU, Metered Outlet, 0U, 3 Phase, 22kW, 230V, 32A, (18) C13 and (6) C19 outlets, IEC60309 3P+N+PE inlet

£1422.52

£1707.02 inc. VAT

Out of Stock(0)MPN: EPDU2232MBO
🚚 Next-day delivery £4.95
Quantity:1
1
2
3
4
5
6
7
8
9
10+

Key Features

APC EasyPDU EPDU2232MBO
Power distribution unit (rack-mountable)
metered-by-outlet
AC 400 V
22 kW
22000 VA
3-phase
Ethernet 10/100, serial, USB

Product Overview

AI-generated summary

For the price (£1422 ex-VAT) this APC Easy Rack metered 0U PDU is a “proper utility” piece of kit, not a budget afterthought. If you’re running a cabinet with multiple power-hungry loads and you want to see what’s actually happening per site (rather than guessing from breaker trips or billing estimates), the metering is the difference between “we think it’s fine” and “we know what’s pulling current.” The outlet mix also makes it practical in a typical UK rack build: enough C13 for generic kit, plus C19 where you’ve got heavier draws (storage, line-cards, or dense lab gear).

That said, I wouldn’t buy this just because it’s APC-branded. It’s a 3‑phase, higher-capacity unit, so it only makes sense if your facility can support that input cleanly and your deployment actually benefits from 3‑phase distribution—otherwise you’re paying for capability you can’t use. Also, check compatibility with your cabinet layout and inlet arrangement before committing; a 0U PDU is convenient, but routing and managed cable discipline matter more than people expect. Bottom line: good value if you’re standardising on rack power monitoring for real infrastructure deployments; avoid it for small/one-off racks, single-phase environments, or setups where you won’t act on the metering data.

Specifications

Design

PDU typesMetered
TypeThree-phase
Rack capacity0U
MountingVertical
Housing materialAluminium

Ports & interfaces

AC outlets quantity32 AC outlet(s)
Power plugC13 coupler
AC outlet typesC13 coupler,C19 coupler

Features

Daisy chainN
Reset buttonY
LED indicatorsY
Cable length3 m

Management features

MonitoringCurrent,Power,Voltage

Power

Nominal input voltage400 V
AC input frequency50/60 Hz
Maximum current32 A
Nominal output voltage230 V
Output voltage230 V

Certificates

Compliance certificatesCE,RCM,REACH,RoHS,cTUVus,UKCA
CertificationCE, TUV, EN 62368-1, RCM, UKCA

Operational conditions

Operating temperature (T-T)-5 - 50 °C
Storage temperature (T-T)-25 - 65 °C
Operating relative humidity (H-H)5 - 95 %
Storage relative humidity (H-H)5 - 95 %
Operating altitude0 - 3000 m

Weight & dimensions

Width55 mm
Depth56 mm
Height1800 mm
Weight8380 g
